DPHB-50-A2
Specification:
Production Capacity: 10 Tons/hour (based on 50kg/bag)
Suitable Raw materials: granular, powder or mixture of powder and granular are available.
Feeding Method: Screw feeder for powder materials.
Bagging capacity: 25kg/bag-50kg/bag available
Formulation accuracy ≤±0.2%，bagging accuracy ≤±0.2% ；
Kinds of Materials: 4-8 kinds
Recipes of Fertilizer are easy to change according to customer’s specific requirements；Formulation can be changed rapidly in the manufacturing process to accommodate special orders or customer needs.
Description
DPHB-50-5A2 Automatic BB fertilizer formulating, blending and bagging system is a proprietary product developed by Qinhuangdao Sannong Modern Mechanical Equipment Co., Ltd with patents. The first single bag blending and bagging system was built in 2001. It has well performed in domestic and overseas markets since then. It is suited for low production rate from 5 tons/ hour to 15 tons/hour.
It formulates,blends and packs fertilizer one bag at a time with bag weight from 20 Kg through 50 Kg. This eliminates segregation of the blends caused by difference of granule size and density of the ingredient materials and improves formulation accuracy. This system is well suitable for operation in humid area as the way of operation minimizes moisture to get access to the blends. This system is fully automatic, high in precision and speed, less floor occupancy and easy in operation and maintenance. The stainless steel components give the equipment sound anti-corrosion capability and long service life.
DPHB-50-4A2
Specification:
Blending capacity: 50kg/time
Output: 10tons/h; 15tons/h;
Suitable Raw materials: powder or mixture of powder and granular are available.
Feeding Method: Belt Feeder for Powder Fertilizer blending System
Packaging: 25kg/bag-50kg/bag available
Batching accuracy ≤±0.2%，Packaging accuracy ≤±0.2% ；
Kinds of Materials: 4-8 kinds
Recipes of Fertilizer are easy to change according to customer’s specific requirements；
Description
Single bag batching and blending system is the patents of SANNONG; it features that one batch blending for one bag, each time can be blended 25kg to 50kg by according to your requirements, combine with good quality and homogeneous mixtures. It also solves the segregation phenomenon of bulk blend fertilizer and improves the batching precision.
It is the specialized equipment for BB fertilizer production which combines the auto batching blending and packaging in integration. This production line is characterized by full automatic, high precision, high speed, small floor space and easy operation and maintenance, low cost investment; it is used stainless steel with strong anticorrosive capability and long service life.
DPHB-150-6
Specification
Blending capacity: 200-300kg/time
Output: 15tons/h
Raw Materials: powder, mixtures of powder and granular.
Batching scale: Static belt weighing scale
Packaging: 25kg/bag-50kg/bag available
Batching accuracy ≤±0.2%，
Packaging accuracy ≤±0.2% ；
Kinds of Materials: 4-8 kinds
Recipes of Fertilizer is easy to change according to customer’s need；
Description
It is suitable for large production requirements. Materials batched under the floor by Static belt metering scale, this system is able to solve the weakness of metering errors induced by dynamic metering in ordinary belt scale, improve the output and batch precision.
It is the specialized equipment for BB fertilizer production which combines the auto batching blending and packaging in integration. This production line is characterized by full automatic, high precision, high speed, small floor space and easy operation and maintenance, low cost investment; it is used stainless steel with strong anticorrosive capability and long service life. |
